SPECIFICATION
Adaptor SMA male to MMCX female
(SMA/MMCX-JK)
| Interface According to：IEC 60169-15/CECC22340 | |
Electrical Performance Characteristic Impedance：50 ohm Frequency Range：DC-3GHz VSWR：≤1.2 Dielectric Withstanding Voltage：≥1000V RMS,50Hz,at sea level Dielectric Resistance：≥1000MΩ Contact Resistance：Center Contact ≤2.5mΩ Outer Contact ≤5mΩ Durability：Mating cycles ≥500 | Material and plating Body：Brass, Au plating Insulator：PTFE, NATURAL Contact PIN：Phosphor Bronze,Au plating
Environmental Temperature Range：-40℃～+85℃ Waterproof：P67 RoHS：Full RoHS-Compliance |
All products appearance, technical performance and electroplating can be customized according to customer requirements.
